Size (CM)：N/A

Weight (KG)：0.14

Overview

The 856A3267G02 is a  Adaptor Test Ring specifically engineered for the CFM56 engine testing and validation program. This specialized component plays a dual role in ground support and test cell environments: it provides critical bearing support for precise mechanical alignment and serves as a vital interface for airflow checks. Additionally, the 856A3267G02 is designed to support test stand oil tube assemblies, ensuring that fluid and pneumatic systems are securely positioned and fully operational during rigorous engine performance evaluations.

Key Points

Integrated Testing Support: Multi-functional design that facilitates both structural bearing support and aerodynamic airflow verification within the test rig.

Leak-Free Fluid Interface: Specifically configured to secure oil tube assemblies, preventing vibration-induced leaks or misalignments during high-pressure testing cycles.

Engineered for Test Cells: Optimized for use in Engine Test Cells and specialized maintenance docks, ensuring seamless integration with standard CFM56 testing hardware.

Aerospace-Grade Precision: Manufactured from high-strength, heat-resistant materials to maintain dimensional stability under the intense thermal and mechanical stresses of active engine testing.

Application.

Performance Validation: Essential for airflow and pressure checks to ensure the engine meets OEM performance specifications before being returned to service.

Lubrication System Testing: Used to stabilize oil tubes and supply lines, allowing for accurate monitoring of the engine's lubrication and cooling systems.

MRO Final Inspection: A critical tool for Maintenance, Repair, and Overhaul (MRO) facilities to verify structural and fluid integrity post-assembly.
